The Hoyles EX105SF is a flush mount 12vdc powered Stainless Steel Exitguard Ideally suited for more prestigious buildings or anywhere where flush mount equipment is required. Use where the protected door may be opened frequently or the sounder may need to sound for a long time. This version can also be used as part of a system where it is necessary to interface with other equipment such as intruder alarms or access control systems. There is an alarm output relay for connection to remote systems.

Please note: This version cannot be powered by batteries.

Hoyles EX105SF Flush Exitguard With Integral Keyswitch Features

• Keyswitch Control
• 12vdc Powered
• Alarm Relay Output
• High Power Piezo Sounder
• Auto Re-arm & Reset Delay (variable)
• Optional Door Open Too Long delay 15s
• Visual Alarm Indication
• Tamper Switch
• Separate Tamper Tone with Manual Reduction
• IMPROVED Chime Facility
• NEW Selectable Alarm Tones
• NEW Simple Function Change by Internal Jumpers
• Door contact supplied
•

Facia Dimensions 180mm x 125mm x 2mm Back Box Dimensions 165 x 100 x 55mm

Supplied with full fitting instructions, including wall fixings, door contact, 1 metre of cable and door warning label.
