The Kentec K41108FST master panel can answer or call out to each, multiple or all of the Safe-Point disabled refuge outstations by activating the corresponding fascia push-buttons. Once connected full duplex conversations can take place and calls are ended by simply replacing the integrated handset.

Accompanying LED indicators and an internal buzzer notify of any disabled refuse alarms raised. A fascia located momentary push-button provides lamp-test and buzzer silence functionality. Added LED’s provide power health and system fault indications.

The unit is wired to disabled refuge outstations by radial type circuits. Any toilet alarm kit can be wired in-line with an accompanying disable refuge call/answer point.

Space for 7Ah batteries is provided within the cabinet, these will provide 24 + 3 hours standby as specified by BS5839 Part 9.  The unit is available in surface or flush mount enclosure options, comprising a mild steel back box with stainless steel fascia plate, including a tamper resistant vision window cover.

Kentec K41108FST Safe-Point EVCS 8 Line Central Unit Features

• Disable Refuge Combined Master Panel
• 8x Call/answer outstation inputs
• Simple, handset operation
• Alarm indicators and internal buzzer
• Power on and system fault indicators
• Lamp test and silence buzzer push button
• Enable ‘In Fire’ input to prevent non-essential calls
• Integrated display to show custom alarm information
• Tamper resistant vision window cover
